| Product application |
Electric vehicle |
| Mechanical properties |
Mechanical life: no-load plug> 10000times |
| Insertion force: <100N |
| Electrical Performance |
The rated current: 10A、16A、32A、63A |
| The rated voltage: 250V/415V |
| Insulation resistance: >1000MQ(DC500V) |
| Pins temperature rise：<50K |
| Withstand voltage: 2500V |
| Contact impedance: 0.5mQMax |
| Applied Materials |
Shell Material: thermoplastics, lame retar-dant grade UL94-V0 Contact-tube: Copper alloy, silver-plated |
| Environmental performance |
Operating temperature: -30 ℃ ~ +50 ℃ |
| Features |
1.Conform to the provisions and requirements of GB/T 20234, .2-2015. |
| 2.Have a electromagnetic locking device (can match with hela lock), have functions of signal feedback. |
| 3.Have one or two PTC(PT1000) thermistor (can match with hela lock), have functions of signal feedback. |
| 4.Beautiful appearance, prevention cap can be installed on the left side, the right side or the front of it. |
| 5.Reliable material flame retardant, presssure proof, wear – resisting, impact resistance, high oil proof. |
| 6.Excellent protection performance, prodection grade achieved IP55( working condition). |
